Planetary Mixers

40L Mixer (Belt)

Industrial Scale, Refined Transmission

The Rasbake B-40 is a high-volume industrial titan designed for the rigorous demands of large-scale production. Featuring a heavy-duty belt-driven transmission and a robust 130 kg chassis, this 40-liter planetary mixer delivers relentless power and smooth operation, ensuring consistent gluten development and perfect aeration for up to 9.0 kg of flour.

10L Mixer (Gear)
B-10
20L Mixer (Gear)
B-20
20L Mixer (Belt)
B-20F

Overview

The Rasbake B-40 is engineered for high-output commercial environments that require a massive capacity without compromising on operational smoothness. This 40-liter powerhouse utilizes a heavy-duty belt-driven system to deliver high-torque performance while effectively damping mechanical noise and vibration. Built into a formidable 130 kg floor-standing structure, the B-40 provides the unshakeable stability necessary for handling heavy batches of up to 9.0 kg of flour. With its minimal industrial silhouette and precise three-speed control, it represents the peak of standard industrial mixing technology.

Technical Specifications

Capacity 40 L (Max Flour: 9.0 kg)
External Dimensions 608 x 531 x 1016 mm
Working Speeds 65 / 102 / 296 RPM
Power Requirements 2.0 kW | 380V/50-60Hz (Three Phase)
Transmission Belt Drive
Weight 130 kg

Key Features

▸ Heavy-Duty Belt Drive

Engineered to handle massive loads with a smoother, quieter operation than gear-driven counterparts, reducing workplace noise while maintaining high torque.

▸ Three-Phase Power Efficiency

Operates on 380V for superior motor stability and energy efficiency during continuous high-volume production cycles.

▸ Industrial Floor-Standing Build

A robust 130 kg frame ensures the unit remains perfectly stationary, even when processing maximum capacity batches at high speeds.

▸ Integrated Safety System

Features a standard safety cover to protect operators during intensive mixing cycles, meeting strict commercial safety standards.

▸ Consistent Planetary Action

Guarantees total bowl coverage and uniform ingredient incorporation, essential for standardized high-quality bakery products.

Ideal Applications

Perfect for large industrial bakeries, wholesale pastry commissaries, and high-volume food production facilities that require a quiet, massive-capacity mixer for continuous daily operation on three-phase power.

Download Our Brochure

Get the complete details of our products, features, and specifications in one downloadable brochure. Stay informed and make the right choice.

Have a question? Contact Support
